Description
Models & Specifications
| Model | MET580R | MET580TR | |
| Optical System: | Infinity Optical System | • | • |
| Microscope Body: | Microscope body for reflected light | • | |
| Microscope body for both transmitted & reflected light | • | ||
| Viewing Head: | Bincoular head with eyetube 30° inclined Ø 30 mm tubes. Interpupillary distance 47-78mm | ○ | ○ |
| Trinocular head with eyetube 30° inclined Ø 30 mm tubes. Interpupillary distance 47-78mm, Light distribution 50/50 | • | • | |
| Trinocular head with eyetube 30° inclined Ø 30 mm tubes. Interpupillary distance 47-78mm, Light distribution 100/0, 0/100 | ○ | ○ | |
| Digital head with eyetube 30° inclined Ø 30 mm tubes. Interpupillary distance 47-75mm, integrated with 4K 8MP camera 1/2.5″ CMOS, with HDMI, USB, Lan, microUSB ports & Wifi function, buttons with image capture & white balance | ○ | ○ | |
| Eyepiece: | WF10x/22mm eyepiece, with +/-5 degree diopter adjustment | •• | •• |
| WF10x/22mm eyepiece with reticle, with +/-5 degree diopter adjustment | ○ | ○ | |
| WF10x/22mm eyepiece with grid, with +/-5 degree diopter adjustment | ○ | ○ | |
| WF10x/22mm eyepiece with pointer, with +/-5 degree diopter adjustment | ○ | ○ | |
| WF12.5x/16mm eyepiece | ○ | ○ | |
| WF15x/16mm eyepiece, with +/-5 degree diopter adjustment | ○ | ○ | |
| WF20x/12mm eyepiece, with +/-5 degree diopter adjustment | ○ | ○ | |
| WF30x/8mm eyepiece, with +/-5 degree diopter adjustment | ○ | ○ | |
| Nosepiece: | Backward Quintuple Coding Nosepiece, type A (work with infinite plan BF objective ) | ○ | ○ |
| Backward Quintuple Coding Nosepiece, type C (work with infinite plan BF/DF objective ) | • | • | |
| Objective: | Infinite plan metallurgical objective 5x/0.15, WD: 20mm (for BF) | • | ○ |
| Infinite plan metallurgical objective 10x/0.3, WD: 11mm (for BF) | • | ○ | |
| Infinite plan metallurgical objective 20x/0.45, WD: 3.1mm (for BF) | • | ○ | |
| Infinite plan metallurgical objective 50x/0.5, WD: 10.6mm (for BF) | • | ○ | |
| Infinite plan metallurgical objective 100x/0.80, WD: 3.5mm (for BF) | • | ○ | |
| Infinite plan metallurgical objective 5x/0.15, WD: 20mm (for BF & DF) | ○ | • | |
| Infinite plan metallurgical objective 10x/0.5, WD: 11mm (for BF & DF) | ○ | • | |
| Infinite plan metallurgical objective 20x/0.45, WD: 3.1mm (for BF & DF) | ○ | • | |
| Infinite plan metallurgical objective 50x/0.5, WD: 10.6mm (for BF & DF) | ○ | • | |
| Infinite plan metallurgical objective 100x/0.80, WD: 3.5mm (for BF & DF) | ○ | • | |
| Infinite Plan Semi-Apochromatic infinity corrected objective, N-MPFN 5x/0.15, WD: 20mm (for BF & DF) | ○ | ○ | |
| Infinite Plan Semi-Apochromatic infinity corrected objective, N-MPFN 10x/0.30, WD: 11mm (for BF & DF) | ○ | ○ | |
| Infinite Plan Semi-Apochromatic infinity corrected objective, N-MPFN 20x/0.45, WD: 3.1mm (for BF & DF) | ○ | ○ | |
| Infinite Plan Apo 50x/0.80 materials sciences objective, WD: 1mm (for BF & DF) | ○ | ○ | |
| Stage: | Stage size 238x140mm, moving range: 78x54mm, 1mm per grid, accuracy 0.1mm; with reflective metal stage plate | • | / |
| Stage size 238x140mm, moving range: 78x54mm, 1mm per grid, accuracy 0.1mm; with transparent and reflective glass stage plate | / | • | |
| Stage size 210mmx170mm Moving range: 4 “X4” (105x105mm), 1mm per grid, accuracy: 1mm; with hard oxidized surface to prevent wear, Y direction is lockable | ○ | ○ | |
| Wafer brackets, for 2 “,3 “,4 “wafer mounts | ○ | ○ | |
| Wafer rack, used for wafer bracket installation | ○ | ○ | |
| Load glass substrate, size :145(X)x152(Y)mm | ○ | ○ | |
| Stage plate, size :145(X)x152(Y)mm | ○ | ○ | |
| Focusing: | Low-hand position coarse and fine coaxial focusing mechanism, Coarse Stroke 37.7mm per Rotation, Fine division 0.002mm, Fine Stroke 0.2mm per Rotation, Focal Disatnce 30mm, With adjusting elastic device and upper limit, with platform up and down adjustment mechanism | • | • |
| Condenser | LWD Condenser NA0.65, WD 10.2 | / | • |
| NA0.9 Condenser | / | ○ | |
| Reflected light: | Metallurgical Epi-Illuminator for BF, with solt for polarization kits & filters | ● | / |
| Metallurgical Epi-Illuminator with BF, DF modules, with solt for polarization kits & filters | / | ● | |
| 3W LED light | ● | / | |
| 3W LED light (the LCD screen on the front of the microscope displays the use status of the microscope, including magnification, light intensity, standby status, lock etc.) | / | ● | |
| Polarizer & analyzer set for reflected light | ○ | ○ | |
| Green filter | ○ | ○ | |
| Frosted filter | ○ | ○ | |
| Transmitted light: | 3W LED light | / | ○ |
| Polarizer & analyzer set for transmitted light | / | ○ | |
| DIC kit | DIC kit for (5x-100x) | ○ | ○ |
| Supplied with | Dust cover, manual | ● | ● |
| Power: | 100-240V, 50/60Hz | ● | ● |
| C mount: | 1X C mount for digital camera | ○ | ○ |
| 0.5X C mount adapter for digital camera | ● | ● | |
