Description
Specifications
| Optical system | Infinity corrected optical system |
| Viewing head | Seidentopf trinocular viewing head inclined at 30°, interpupillary 47-75m, 360° rotation |
| Eyepiece | A pair of WF10x/20mm eyepiece |
| Nosepiece | Reversed quadruple ball bearings revolving nosepiece |
| Objectives | All with anti-fungus treatment. |
| Infinite plan achromatic objective 4x/0.10 | |
| Infinite plan achromatic objective 10x/0.25 | |
| Infinite plan achromatic objective 40x/0.65, spring loaded | |
| Infinite plan achromatic objective 100x/1.25, spring loaded, oil (optional) | |
| Stage | Precision XYZ digintal motorized autofocus stage: |
| 1. XYZ digtal motorized precision autofocus platform; | |
| 2. Effective stroke: X=80mm, Y=60mm; | |
| 3. Number of slices scanned at one time: 1; | |
| 4. Precision scanning motor; | |
| 5. Equipped with precision anti-backlash screw; | |
| 6. Limiting method: soft limit + photoelectric limit + mechanical limit; | |
| 7. Resolution: < 0.05 um; | |
| 8. Maximum speed: 50 mm/s | |
| 9. One-way repeatability: ≤ 1 μm; | |
| 10. Bidirectional repeatability: ≤ 2.5 μm | |
| 11. Absolute positioning accuracy / 10mm: ≤ ±2 μm; | |
| 12. Guide rail: Cross roller guide rail | |
| Focusing | Integrated design, coaxial focus system with upper limited and tension adjustment, coarse stroke 37.7mm per rotation, fine precision: 0.002mm, fine stroke 0.2mm per rotation, moving range: 25mm, provided with an adjustable tightness device to prevent slipping and a mechanical upper limit device |
| Condenser | Sliding-in centerable abbe condenser 1.25 NA with objective position scales |
| Illumination | High brightness energy-saving S-LED illumination for long life, brightness adjustable |
| Power | Multi-plug 100-240Vac, 50/60Hz external power supply |
| Digital camera | UNISON-2PA digital camera, 2 megapixel, 1/2″ CMOS, USB3.0, and a 3.75um x 3.75um pixel, exposure time of 0.1ms-15s, FPS/Resolution: 125@1920×1080, with image process software |
| Usage environment | Temperature 5～30℃ |
| Humidity 45～85% | |
| Vibration Shockproof Workbench (Optional) | |
| PC configuration (Optional) | Recommended configurations |
| CPU Intel Core i7 | |
| Memory DDR4 16G | |
| Hard disk 7200rpm >1TB | |
| Monitor 24 inches |
